MXL Pitch Aluminum Timing Pulley with Pilot Bore
Our MXL pitch timing pulleys deliver precise motion control for compact automation and precision instruments. Machined from aluminum alloy with pilot bore, these pulleys offer reliable performance with minimal inertia. Available in 10 to 120 teeth, with H7 bore tolerance and radial runout ≤0.03 mm, they meet ISO 13050 and DIN standards. Backed by 100% dimensional inspection, they ensure consistent quality for demanding applications.
Key Selling Points
- High tooth accuracy: Conforms to ISO 13050 and DIN with radial runout ≤0.03 mm, ensuring smooth and accurate synchronization.
- Lightweight aluminum: Reduces inertia for high-speed operation (up to 8,000 rpm), ideal for precision instruments.
- H7 bore tolerance: Provides precise shaft fit, minimizing vibration and wear.
- Wide tooth range: 10-120 teeth with custom options available, fitting diverse design needs.
- 100% inspection: Every pulley undergoes dimensional check before shipment, assuring reliability.
Technical Specifications
| Tooth Profile | Imperial Trapezoidal (MXL) |
| Available Pitches | MXL (0.080" pitch) |
| Material | Aluminum Alloy |
| Number of Teeth | 10–120 (Custom Available) |
| Bore Type | Pilot Bore |
| Bore Diameter | 3–100 mm (Custom Available) |
| Surface Treatment | Natural, Black Oxide, Zinc Plated, Hard Anodized, Nickel Plated |
| Tooth Accuracy | ISO 13050 / DIN Standard |
| Radial Runout | ≤0.03 mm |
| Bore Tolerance | H7 (Finished Bore) |
| Max. Operating Speed | Up to 8,000 rpm |
| Operating Temperature | -30°C to +120°C |
| Compatible Belts | Imperial Rubber Timing Belts, Imperial PU Timing Belts |
| Manufacturing Process | CNC Machining, Gear Hobbing |
Models and Options
Available in various tooth counts (10-120) and bore types (pilot, finished, taper, keyway). Custom options include bore diameter, hub type (single, double, hubless), and flange type (single, double, without).
Materials and Structure
Constructed from high-strength aluminum alloy, providing lightweight durability. Available surface treatments: natural, black oxide, zinc plated, hard anodized, nickel plated.
Applications
Ideal for precision instruments, robotics, small automation systems, and applications requiring high precision and low inertia.
Customization
OEM/ODM available. Custom teeth, bore, hub, flange, and surface treatment can be provided. 100% dimensional inspection before shipment.
FAQ
- What is the MOQ? MOQ is 10 pcs for standard models, 50 pcs for customized belts.
- What are the delivery terms? EXW Dongguan, FOB Shenzhen, CIF, DDP (selected countries).
- What is the lead time? Regular models can ship within 3 days; custom gears and racks support drawing machining with 7-day lead time.
- Can I get samples? Yes, PayPal accepts sample orders.
- What quality certifications do you have? We have RoHS (SGS) and TÜV Rheinland factory audit reports.
